Jacket Bag Filter
-
Filter Area
50-500㎡ -
Plate Quality
28-123 -
Filter volume
736-8735L
Product Description
Jacket bag filter housing. It has double-layer structure.There is a layer of heat preservation on the outside of the vessel, and the layer has an inlet and an outlet, steam or hot water or heat transfer oil can be passed into the jacket for circulation. It maintains or increases the temperature of the fluid in the filter vessel, prevent the fluid from crystallizing and solidifying due to the temperature drop, and improve the filtration speed of viscous liquids.
The equipment is widely used in: Chemical, food, beverage, pharmacy and other industries for rough and fine filtration, and it performs steam heating or condensation cooling for filter suspension with high viscosity or requiring heat preservation.
Product video
| Model | Bag QTY | Filter Area（㎡） | Max Flow（t/h） | Inlet/Outlet | Heating Inlet/Outlet | Working Pressure(Mpa) | Housing Diameter(mm) | Total Heigh（mm） | Housing Height（mm） | Center Distance of Foundation Bolts（mm） |
| DL-2P2S | 2 | 1 | 70 | DN65 | DN25 | 0.5 | 456 | 1572 | 1144 | 696 |
| DL-3P2S | 3 | 1.5 | 105 | DN80 | DN25 | 508 | 1592 | 1190 | 748 | |
| DL-4P2S | 4 | 2 | 140 | DN100 | DN25 | 558 | 1632 | 1244 | 798 | |
| DL-5P2S | 5 | 2.5 | 175 | DN150 | DN25 | 608 | 1788 | 1254 | 848 | |
| DL-6P2S | 6 | 3 | 210 | DN150 | DN25 | 658 | 1854 | 1300 | 898 | |
| DL-7P2S | 7 | 3.5 | 245 | DN150 | DN25 | 710 | 1875 | 1340 | 950 | |
| DL-8P2S | 8 | 4 | 280 | DN150 | DN25 | 760 | 1922 | 1404 | 1000 | |
| DL-10P2S | 10 | 5 | 350 | DN200 | DN32 | 910 | 2004 | 1430 | 1170 | |
| DL-12P2S | 12 | 6 | 420 | DN200 | DN32 | 962 | 2064 | 1460 | 1232 | |
| DL-14P2S | 14 | 7 | 490 | DN200 | DN32 | 1012 | 2124 | 1490 | 1312 | |
| DL-16P2S | 16 | 8 | 560 | DN250 | DN32 | 1112 | 2146 | 1512 | 1412 | |
| DL-18P2S | 18 | 9 | 630 | DN250 | DN32 | 1162 | 2225 | 1595 | 1462 | |
| DL-20P2S | 20 | 10 | 700 | DN250 | DN32 | 1212 | 2280 | 1640 | 1512 | |
| DL-22P2S | 22 | 11 | 770 | DN250 | DN32 | 1366 | 2320 | 1694 | 1616 | |
| DL-24P2S | 24 | 12 | 840 | DN300 | DN32 | 1416 | 2358 | 1748 | 1716 |
