Single Bag Filter
-
Filter Area
50-500㎡ -
Plate Quality
28-123 -
Filter volume
736-8735L
Product Description
The single bag filter is a new type of filtration system. The filter bag is supported by a metal basket inside the filter. The liquid flows in from the inlet and flows out from the outlet after filtering by the filter bag. The impurities are trapped in the filter bag and the bag filter can continue to be used after changing the filter bag. It is very convenient to change the filter bag, no material consumption and low operation cost.
Equipment is widely used in: chemical, pharmaceutical, automotive, light industry, food, electroplating and other industries
| Model | Filtering Area（㎡） | Max Flow（t/h） | Working pressure（Mpa） | Volume（L） | Inlet/Outlet Connection | Housing Diameter(B.mm) | Total Heigh（H.mm） | Housing Heisght(H1.mm) |
| 01# | 0.25 | 20 | 0.5 | 8 | DN40 | 220 | 220 | 568 |
| 02# | 0.5 | 40 | 0.5 | 17 | DN50 | 220 | 220 | 960 |
| 04# | 0.2 | 10 | 0.5 | 4 | DN32 | 159 | 159 | 568 |
